产品规格
型号：EN35005
功率：5W、7W、10W、12W
光束角：15° 24° 36°
散热器：铝
表面处理：喷漆
开孔：Φ75mm
功率：5W、7W、10W、12W
光束角：15° 24° 36°
散热器：铝
表面处理：喷漆
开孔：Φ75mm
可选配件
产品参数
| 产品名称 | 型号 | 功率 | 电压/电流 | 显色性 | 光束角 | 色温 | 光强 | 照度表 | IES | 说明书 |
|---|---|---|---|---|---|---|---|---|---|---|
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 15° | 2700K | 2398CD |  | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 15° | 3000K | 2524CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 15° | 4000K | 2657CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 24° | 2700K | 2116CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 24° | 3000K | 2228CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 24° | 4000K | 2345CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 36° | 2700K | 1086CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 36° | 3000K | 1143CD | | | |
| 嵌⼊式象⿐灯 | EN35005-005 | 5W | 37V/120mA | Ra>90 | 36° | 4000K | 1203CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 15° | 2700K | 3357CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 15° | 3000K | 3534CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 15° | 4000K | 3720CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 24° | 2700K | 2963CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 24° | 3000K | 3119CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 24° | 4000K | 3283CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 36° | 2700K | 1520CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 36° | 3000K | 1600CD | | | |
| 嵌⼊式象⿐灯 | EN35005-007 | 7W | 37V/150mA | Ra>90 | 36° | 4000K | 1684CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 15° | 2700K | 4588CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 15° | 3000K | 4829CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 15° | 4000K | 5084CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 24° | 2700K | 3499CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 24° | 3000K | 3684CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 24° | 4000K | 3877CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 36° | 2700K | 1786CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 36° | 3000K | 1880CD | | | |
| 嵌⼊式象⿐灯 | EN35005-010 | 10W | 37V/250mA | Ra>90 | 36° | 4000K | 1979CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 15° | 2700K | 5471CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 15° | 3000K | 5759CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 15° | 4000K | 6062CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 24° | 2700K | 4206CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 24° | 3000K | 4427CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 24° | 4000K | 4660CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 36° | 2700K | 2141CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 36° | 3000K | 2254CD | | | |
| 嵌⼊式象⿐灯 | EN35005-012 | 12W | 37V/300mA | Ra>90 | 36° | 4000K | 2373CD | | | |
